| Thread Diameter Size (TDZ) | 1/2″ | Applicable Material | Steel | Cast Iron | Aluminum / Non-Ferrous Materials |
| Threads per Inch (TPI) | 14 | Chamfer | 2.5P |
| Thread Standard | NPT | Coating | Black Oxide |
| Usable Length (LU) | 1.374″ | Cutting Edge Material | HSS |
| Flute Count (NOF) | 4 | Measurement Type | Inch |
| Overall Length (OAL) | 3-1/8″ | Series/List # | 108 |
| Thread Cutting Part Length (THL) | 1-3/8″ | Thread Size | 1/2″ - 14 |
Product Features
| Remarks | •Regular thread •OSG List #108. | Country of Origin | Mexico |
Shipping Info
Package Length
3.30000
Package Width
.90000
Package Height
.90000
Package Weight
0.285
